輸入/輸出規格參數[Input/Output
Specifications]:
|
|
|
輸入電壓[Input Voltage]:
AC
100-240V,50/60Hz
|
|
|
輸出功率[Output Power]:
12W
|
|
|
輸出電壓[Output Voltage]:
3-36V
|
|
|
輸出電流[Output
current] 0.1-2000MA
|
|
|
過壓保護[Over Voltage Protection]:
120%min
|
|
|
過流保護[Over Current Protection]:
120%min
|
|
|
短路保護[Short Protection]:
Auto
Recove
|
|
|
輸出電壓變動[Load Regulation]:
±5%
|
|
|
一般參數規格[General Specifications]
|
|
工作環境溫度[Operating Temperature]:
0~40℃
|
|
儲存溫度[Storage Temperature]:
-20~85℃
|
|
工作溫度[Operating Relative Humidity]:
5~95%RH
|
|
耐壓[Withstanding Voltage]:
AC
2000V(Min),5mA(Max)
|
|
絕緣抗體[Insulation Resistance]:
DC
500V 100MΩ(Min)
|
