核子級拋光樹脂杜笙 Tulsion MB-106UP NUCLEAR GRADE RESIN FOR PRODUCTION OF ULTRA PURE WATER 杜笙TULSION MB-106 UP 是由核子級強酸型陽離子杜笙TULSION T-46 及核子級強堿型陰離子杜笙TULSIONA-33 以1:2 體積比的劑量比例 , 預先混合的混床級離子交換樹脂,專門提供給須要高純水系統拋光用。杜笙TULSION MB-106 UP is a mixture of strongly acidic cation resin 杜笙TULSIONT-46 in H+ form and strongly basic anion exchange resins 杜笙TULSION A-33 in OH- form in stoichiometric equivalent quantities. 杜笙TULSION MB-106 UP 是專門用于超純水的最后段的拋光處里。杜笙TULSIONMB-106 UPis designed for use in the final polishing for production of ultra pure water. 杜笙TULSION MB-106 UP適合用于電子產業 ，生產半導體及映像管產業等需要超純水的行業。具有高的交換容量及優越的物理特性。 杜笙TULSION MB-106 UP is the ideal choice for electronic industries which manufacture semi-conductors and television tubes etc. where ultra pure water is required. The resin combines high capacity with excellent physical properties TYPICAL CHARACTERISTICS ---------------------------------------- 基 本 特 性
| |
TULSION T-46 (陽) |
TULSION A-33 (陰) |
| 型式(Type) |
強酸性陽離子交換樹脂 (Strong acid Cation exchange resin) |
強堿性陰離子交換樹脂 (Strong base Anion exchange resin) |
| 主體結構(Matrix Structure) |
苯乙烯(Cross linked polystyrene) |
苯乙烯(Cross linked polystyrene) |
| 功能基 (Functional Group) |
硫酸基(Sulfonic acid) |
4級胺(Quaternary ammonium Type I) |
| 物理性貭(Physical Form) |
球狀顆粒(Moist spherical beads) |
球狀顆粒(Moist spherical beads) |
| 離子型式(Ionic form supplied) |
氫(Hydrogen) |
氫氧(Hydroxide) |
| 粒徑范圍(U.S.mesh in wet) |
16 to 50 |
16 to 50 |
| 粒度范圍 (Particle Size) |
0.3 to 1.2 mm |
0.3 to 1.2 mm |
| 微粒含量(Fines Content) |
穿過US 50 Mesh小于0.5% (Less than 0.5% passing through 50 U.S.mesh) |
穿過US 50 Mesh小于0.5% (Less than 0.5% passing through 50 U.S.mesh) |
| 總交換容量 (Total Exch. Capacity) |
1.8 meq/ml minimum of 99% in hydrogen form |
1.0 meq/ml minimum of 90% in hydroxide form and less than 1% in chloride form |
| PH范圍 (pH Range) |
0 to 14 |
0 to 14 |
| 允許溫度 (Temp. Stability) |
120°C |
60°C |
| 溶解率 (Solubility) |
Insoluble in all common solvents |
Insoluble in all common solvents |
| 溶出有機物(Organic leachable) |
Less than 0.2 mg KMNO4 per ml of wet resin |
Less than 0.2 mg KMNO4 per ml of wet resin |
| 密度Backwash settled density |
Approx.750 gm/liter |
Approx.750 gm/liter |
| 不純物(Impurities) |
Fe=50 ppm(max) |
Fe=50 ppm(max) |
| |
Cu=50 ppm(max) |
Cu=50 ppm(max) |
| |
Pb=50 ppm(max) |
Pb=50 ppm(max) |
| 球粒強度(Bead strength) |
Avg. not less than 500g/bead by Chatillon test (ASTM Standard) |
Avg. not less than 300g/bead by Chatillon test (ASTM Standard)
|
